One PCIe® 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm)
Three M.2 slots (one for WLAN, two for SSD)
Case Color
Black
Stand
None
Dust Filter
None
Pen
Pen Not Supported
Form Factor
Tower (13.6L)
Dimensions (WxDxH)
145 x 296 x 346 mm (5.7 x 11.7 x 13.6 inches)
Weight
Around 5.9 kg (13.0 lbs)
CONNECTIVITY
WLAN + Bluetooth
None
WWAN
WWAN Not Supported
Ethernet
Integrated 100/1000M
Front Ports
1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging
4x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader
Rear Ports
4x USB-A (Hi-Speed USB / USB 2.0)
1x HDMI® 2.1 TMDS
2x DisplayPort™ 1.4a (HBR2, DSC)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Fingerprint Reader
No fingerprint reader
Physical Locks
Kensington Security Slot™, 3 x 7 mm
Padlock Loop
Smart Cable Clip
None
Chassis E-Lock
None
Chassis Intrusion Switch
Chassis Intrusion Switch
Other Security
Pluton security processor
MANAGEABILITY
System Management
Non-DASH
SERVICE
Base Warranty
3-year, Onsite
Included Upgrade
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 3
GREENGUARD®
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)
