| PERFORMANCE |
| Processor |
Intel Core™ Ultra 5 225U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.8GHz, 12MB Intel® Smart Cache
|
| AI PC Category |
|
| NPU |
Integrated Intel® AI Boost, up to 12 TOPS
|
| Graphics |
Integrated Intel® Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
1x 16GB SODIMM DDR5-5600
|
| Memory Slots |
Two DDR5 SODIMM slots, dual-channel capable
|
| Max Memory
|
Up to 64GB DDR5-5600
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Slot |
One M.2 2280 PCIe® 4.0 x4 slot
|
| Max Storage Support
|
One drive, up to 2TB M.2 2280 SSD
|
| Card Reader |
No Card Reader
|
| Audio Chip |
High Definition (HD) Audio, Senary SN6147 codec
|
| Speakers |
Stereo speakers, 2W x2, optimized with Dolby Atmos®
|
| Microphone |
2x, Array
|
| Camera |
5.0MP + IR Discrete with Privacy Shutter
|
| Battery |
57Wh
|
| Power Adapter |
65W USB-C® (3-pin)
|
| DESIGN |
| Display |
14" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz, DBEF5
|
| Touchscreen |
None
|
| Screen-to-Body Ratio |
85.5%
|
| Pen |
Pen Not Supported
|
| Keyboard |
Backlit, German
|
| Dimensions (WxDxH)
|
313.7 x 226 x 11.39/17.31 (front/rear), 22.9 (maximum) mm; 12.35 x 8.90 x 0.45/0.68 (front/rear), 0.90 (maximum) inches
|
| Weight
|
Starting at 1.38 kg (3.05 lbs)
|
| Case Color |
Black
|
| Case Material |
PC-ABS (Top), PC-ABS (Bottom)
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, German
|
| Bundled Software |
None
|
| CONNECTIVITY |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3
|
| WWAN |
Quectel EM160R-GL, 4G LTE CAT16, with Embedded eSIM
|
| SIM Card |
No physical SIM card inbox
|
| Ethernet |
100/1000M (RJ-45)
|
| NFC |
No NFC
|
| Standard Ports |
- 1x USB-A (Hi-Speed USB / USB 2.0)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.1 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
|
| Optional Ports (configured) |
- 1x Smart Card Reader
- 1x Nano-SIM Card Slot
|
| Docking |
|
| SECURITY & PRIVACY |
| ThinkShield |
ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
| Security Chip |
Discrete TPM 2.0 Enabled
|
| Physical Locks |
Kensington Nano Security Slot™, 2.5 x 6 mm
|
| Smart Card Reader |
Smart Card Reader
|
| Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button
|
| Other Security |
- Camera privacy shutter
- IR camera for Windows® Hello (facial recognition)
- Privacy Guard with Privacy Alert (software solution)
|
| MANAGEABILITY |
| System Management |
Non-vPro®
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
1Y Premier WHB (CPN)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications |
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
