| PERFORMANCE |
| Processor |
Intel Core™ Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB Intel® Smart Cache
|
| AI PC Category |
AI-Ready Workstations
|
| NPU |
Integrated Intel® AI Boost, up to 13 TOPS
|
| Graphics |
NVIDIA® RTX PRO 2000 Blackwell Generation 8GB GDDR7 Laptop GPU
|
| Chipset |
Intel® WM880 Chipset
|
| Memory
|
2x 32GB SODIMM DDR5-5600 Non-ECC
|
| Memory Slots |
Four DDR5 SODIMM slots, dual-channel capable
|
| Max Memory |
- Models with ECC memory: Up to 128GB (4x 32GB SODIMM DDR5-5600 ECC)
- Models with Non-ECC memory: Up to 192GB (4x 48GB SODIMM DDR5-5600 Non-ECC)
|
| Storage |
1TB SSD M.2 2280 PCIe® 5.0x4 Performance NVMe® Opal 2.0
|
| Storage Slot |
Three M.2 slots • One M.2 2280 PCIe® 5.0 x4 slot • Two M.2 2280 PCIe® 4.0 x4 slots
|
| Max Storage Support
|
Up to three M.2 2280 Gen 5 Performance SSD; up to 12TB, 4TB each
|
| RAID Preset |
None
|
| Card Reader |
SD Express 8.0 Card Reader
|
| Audio Chip |
SoundWire®, Cirrus Logic® CS42L43 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos®
|
| Microphone |
2x, Array
|
| Camera |
5.0MP + IR with Privacy Shutter and Computer Vision Human Presence Detection on ISP
|
| Battery |
99.9Wh
|
| Power Adapter |
180W USB-C® GaN (3-pin)
|
| DESIGN |
| Display |
16" WQUXGA (3840x2400) IPS 800nits Anti-glare, 100% DCI-P3, 60Hz, DisplayHDR™ 400, Dolby Vision®, Eyesafe®, TÜV Low Blue Light
|
| Touchscreen |
None
|
| Screen-to-Body Ratio |
82%
|
| Color Calibration |
X-Rite® Factory Color Calibration
|
| Pen |
Pen Not Supported
|
| Keyboard |
Backlit, German
|
| Dimensions (WxDxH)
|
362 x 252 x 15.8 / 20.9 (front / rear), 29.8 (maximum) mm 14.25 x 9.92 x 0.62 / 0.82 (front / rear), 1.17 (maximum) inches
|
| Weight
|
Starting at 2.54 kg (5.6 lbs)
|
| Case Color |
Black
|
| Case Material |
Aluminium (Top), Aluminium (Bottom)
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, German
|
| Bundled Software |
Lenovo® AI Now
|
| CONNECTIVITY |
| WLAN + Bluetooth |
Intel® Wi-Fi® 7 BE200, 802.11be 2x2 + BT5.4
|
| WWAN |
WWAN Upgradable to 5G
|
| SIM Card |
No physical SIM card included
|
| Ethernet |
1x 2.5GbE RJ-45
|
| NFC |
No NFC
|
| Standard Ports |
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 2x Thunderbolt™ 5, with DisplayPort™ 2.1 and USB PD 3.1, 180W input / 15W output
- 1x Thunderbolt™ 4, with DisplayPort™ 2.1 and USB PD 3.1, 180W input / 15W output
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (2.5GbE RJ-45)
- 1x SD Express 8.0 card reader
- 1x Kensington Nano Security Slot™
|
| Optional Ports (configured) |
1x Nano-SIM Card Slot
|
| Docking |
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0 Enabled
|
| Physical Locks |
Kensington Nano Security Slot™, 2.5 x 6 mm
|
| Smart Card Reader |
No Smart Card Reader
|
| Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button
|
| Other Security |
- Camera privacy shutter (camera models)
- Computer Vision-based User Presence Sensing on Image Signal Processor (ISP)
|
| MANAGEABILITY |
| System Management |
Non-vPro®
|
| SERVICE |
| Base Warranty |
3-year, Courier or Carry-in with 1-year Battery
|
| Included Upgrade |
3Y Premier TP WS WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| ISV Certifications |
|
| Green Certifications |
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
| Other Certifications |
- Eyesafe® Certified 2.0
- TÜV Rheinland® Low Blue Light
|
