| PERFORMANCE |
| Processor |
Intel Core™ Ultra 5 228V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB Intel® Smart Cache
|
| AI PC Category |
Copilot+ PC
|
| NPU |
Integrated Intel® AI Boost, up to 40 TOPS
|
| Graphics |
Integrated Intel® Arc™ Graphics 130V
|
| Chipset |
Intel® SoC Platform
|
| Memory |
32GB Soldered LPDDR5x-8533, MoP Memory
|
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
| Max Memory |
32GB soldered memory, not upgradable
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Slot |
Models with V or H series processor: one M.2 2280 PCIe® 5.0 x4 slot
|
| Max Storage Support
|
One drive, up to 1TB M.2 2280 SSD
|
| Card Reader |
No Card Reader
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos®
|
| Microphone |
2x, 360°
|
| Camera |
5.0MP + IR Discrete with Privacy Shutter, Computer Vision on ISP
|
| Battery |
58Wh
|
| Power Adapter |
65W USB-C® Slim GaN (3-pin)
|
| DESIGN |
| Display |
14" WUXGA (1920x1200) IPS 500nits Anti-glare, 100% sRGB, 60Hz, Low Power
|
| Touchscreen |
None
|
| Screen-to-Body Ratio |
88%
|
| Pen |
Pen Not Supported
|
| Keyboard |
Backlit, German
|
| Dimensions (WxDxH)
|
313.6 x 219.4 x 11.43/16.4 (front/rear), 19.75 (maximum) mm 12.35 x 8.64 x 0.45/0.65 (front/rear), 0.78 (maximum) inches
|
| Weight
|
Starting at 1.28 kg (2.82 lbs)
|
| Case Color |
Black
|
| Case Material |
Carbon Fiber Hybrid (Top), Aluminium (Bottom)
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, German
|
| Bundled Software |
Lenovo® AI Now
|
| CONNECTIVITY |
| WLAN + Bluetooth |
Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4
|
| WWAN |
WWAN Upgradable to 5G
|
| SIM Card |
No physical SIM card inbox
|
| Ethernet |
|
| NFC |
No NFC
|
| Standard Ports |
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.1 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Optional Ports (configured) |
- 1x Smart Card Reader
- 1x Nano-SIM Card Slot
|
| Docking |
|
| SECURITY & PRIVACY |
| ThinkShield |
ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
| Security Chip |
Discrete TPM 2.0 Enabled
|
| Physical Locks |
Kensington Nano Security Slot™, 2.5 x 6 mm
|
| Smart Card Reader |
Smart Card Reader
|
| Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button
|
| Other Security |
- Computer Vision-based Human Presence Detection on Image Signal Processor (ISP)
- Camera privacy shutter
- IR camera for Windows® Hello (facial recognition)
|
| MANAGEABILITY |
| System Management |
Non-vPro®
|
| SERVICE |
| Base Warranty |
3-year, Courier or Carry-in
|
| Included Upgrade |
1Y Premier WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications |
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
| Other Certifications |
Eyesafe® Certified 2.0
|
